| Operating Modes |
VVI, VOO, AAI, AOO, DOO, DDD, VDD, DAI |
| Basic Rate |
30 TO 140 PPM IN 1PPM STEP |
| Rapid Rate |
120 to 500 ppm (basic rate x 4 ) |
Output Pulse Amplitude
For both A,V. |
0.2 V to 12 V |
| Pulse Width for both A,V. |
0.1 ms to 1.2 ms in 0.1 ms step |
| Sensitivity |
ATRIUM 0.3 TO 2.4 mV
VENTRICLE 2.0 TO 16 mV |
| A-V Delay |
30 TO 250 ms |
| Resetable Refractory |
ATRIUM : 400ms
VENTRICLE : 313ms |
| Push button for Impedance Measurements |
| Push button for P Wave and R Wave Measurements |
| Easy operation |
| LCD display for read out |
| Pacing Indicators |
